Universal Joint Assembly 1X 5-170X +2 x 1000 Yoke 10-4-453 Ø0.875″x .250 Keyway.

Description

Universal Joint Kit Assembly 5-170X +2x 1000 Yoke 10-4-453 Ø0.875″x .250 Keyway.. fits MudMotor, GoKart, ATV

NB: Here you are buying
2x end yokes and 1x forged steel aftermarket universal
joint 5-170X to make up a kit as seen in the cover image.
These kits are very popular
with ATV’s, Large ride-on Lawn Mowers, Mud motors and any small projects
where you need a driveshaft at an angle.

End Yokes
Series	1000 (0.938 x 1.500 I/C )
(P)	0.875
(R)	1.625
(S)	2.500
(X)	0.250

To be used with universal joint 5-170X U-Joint Series 1000 Bore Diameter P 0.875 SAE Keyway Width X 0.250 Hub Diameter R 1.625 Universal Joint Retaining Width E 1.500 Universal Joint Bearing Diameter D 0.938 Length Thru Bore Q 0.000 Centerline of Joint to End of Hub S 2.500

Imperial Universal Joints
(D)	0.938
(F)	1.500
Type	3

Alternative part numbers for U-JOINT:

CP170X
114-570
1-0170
2240231
4094089
612072
703325
2295607
2296407
2396407
2404877
D-78
338
1501
RL1000
5-110X
1-0172

Additional information

Weight	3 kg
